GE / IP FANUC Series 90/30 In Stock
Other Available Revisions for the IC600BF923 IC600BF923AIC600BF923BIC600BF923CIC600BF923DIC600BF923EIC600BF923FIC600BF923GIC600BF923HIC600BF923IIC600BF923JIC600BF923KIC600BF923LIC600BF923MIC600BF923NIC600BF923OIC600BF923PIC600BF923QIC600BF923RIC600BF923-RRIC600BF923SIC600BF923TIC600BF923UIC600BF923VIC600BF923WIC600BF923XIC600BF923YIC600BF923Z
10-50Vdc Sink Output Module with Lights (32 points) Series 6 Board w Face Plate IC60 IC600BF
The catalog number IC600BF923 is reserved for a sink output module that is available through the Series Six product line by GE Fanuc. The module has 32 output points and it includes both a circuit board and a face plate. The module is of the high-density type and it operates on a voltage range of 10 to 50 Volts DC. The IC600BF923 module is equipped with status indicator lights and it needs an adequate DIP switch setting in order to operate properly. The IC600BF923 module is built for industrial applications and it has a specified operating temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit). Additionally, the unit can be stored at temperatures from -20 to 80 degrees Celsius (-4 to 176 degrees Fahrenheit). Other environmental specifications include 5 to 95% (non-condensing) relative humidity and operating altitude of a maximum of 3048 meters (10,000 feet) above sea level.
The GE Fanuc IC600BF923 sink output module has an isolation voltage rating of 2000 Volts DC for a maximum of one second and it has a maximum voltage rating of 240 Volts AC (at 50 to 60 Hertz) for continuous operation. The output module requires a power source with a voltage rating of 5 Volts DC and a maximum current rating of 180 milliamps. The power should be supplied through the rack onto which the unit is installed. The IC600BF923 sink output module has a power consumption rating of 5 Watts its output goes to the load voltage when in the off-state. The module has a maximum leakage current of 1 milliamp for the off-state and a maximum response time of 40 microseconds whether the device is turned on or turned off.
