IC600YB909

Rated 4.4/5 Based on 8 ratings.

Rate your purchase of the IC600YB909

IC600YB909 48Vdc Source Output Module (8 points) IC600Y IC600YB PDFsupply also repairs GE IP FANUC P

IC600YB909 48Vdc Source Output Module (8 points) IC600Y IC600YB PDFsupply also repairs GE IP FANUC P IC600YB909 48Vdc Source Output Module (8 points) IC600Y IC600YB PDFsupply also repairs GE IP FANUC P

SKU 2178066  UPC 0421882832204

MSRP $2995

"Avg. Repair - 2 Days"

Repair Service

$348

Save $2,647

Fast or Free!

✓  2 Year PDF Supply Warranty

*What is Fast Repair?

Order Today - Ships Today!

*US continental orders placed Monday-Friday before 4:30pm EST!

Lowest Price Guarantee

Other Available Revisions for the IC600YB909 ABCDEFGHIJKLMNOPQRRRSTUVWXYZ

Common misspellings:
  • 1C600YB909
  • lC600YB909
  • IC6o0YB909
  • IC60oYB909
  • IC600Y8909
  • IC600YB9o9
  • IC600YB909

48Vdc Source Output Module (8 points) Series Six Module Without Face Plate IC600Y IC600YB

Technical Information

The GE Fanuc IC600YB909 module is a 48 Volts DC source output module that is designed and manufactured as an accessory for GESeries 6 Programmable Logic Controller (PLC) systems. This solid-state, microprocessor-based electronic module provides 8 independent discrete output points and it can be installed directly in a PLC backplane or a GE Model 60 CPU slot, enabling the GE Series 6 programmable logic controller to manipulate external field devices. In contrast with a sink output module, the GE Fanuc IC600YB909 48 Volts DC source output module provides a positive terminal connection to external field device circuits that should be connected to the negative terminal or ground at the ends. The switching device used in each of the 8 independent outputs is a Darlington amplifier. Some of the applications for this source output module are high-speed switching solenoid valves, annunciators, indicators, or relays.



During the installation of the GE Fanuc IC600YB909 48 Volts DC source output module, it is important to set the Dual-In-Line-Package (DIP) switches in the PLC slot to correspond with 8 bits in the program. Any time this module needs to be inserted into or removed from the backplane, it is important to use the extraction tool that is furnished with the device for this purpose in order to guarantee proper operation with no damage to the delicate connection parts. The GE Fanuc IC600YB909 48 Volts DC source output module comes from the factory with a markable tag next to its 8 LED indicator lights so that each of the circuits can be labeled and identified by the users. The operating temperature range of the device is between 0 and 60 degrees Celsius and the humidity range is between 5 are 95% (non-condensing).
