Product Description


The IC200ERM001 is an Isolated Expansion Receiver Module designed by GE as part of the VersaMax series
. When used in the PLC rack or I/O station, the IC200ERM001 module must be supplemented with an expansion transmitter module (ETM001). The IC200ERM001 is equipped with LEDs that indicate power status and status of the expansion bus. The backplane consumes 5V output maximum and has 3.3V output.

The IC200ERM001 has two female D-shell ports with 26 pins. The upper port receives the cable from the expansion transmitter, while the lower port is designed to daisy-chain the I/O bus cable to the next expansion rack or for the attachment of the terminator plug located on the last rack. Operational power for the module is derived from the installed power supply. If the expansion rack contains a power booster carrier and additional rack power, it must be connected to the identical source on the module.

The IC200ERM001 should be installed in the far left slot of the rack. The module must be attached to the DIN rail at the left end of the expansion rack. The rotary switch under the access door of the IC200ERM001 module is used when selecting the ID of the expansion rack. All I/O and communication modules can be used in expansion racks. When removing the module from the expansion rack, all power must be turned OFF.

GE Intelligent Platforms / GE Fanuc GE Versamax

SKU 2178357  UPC 063968053068

Expansion receiver isolated IC200E IC200ER IC200ERM

Troubleshooting and Product Information for IC200ERM001

Download product information, troubleshooting guides and operation manuals to get your PLC operational.

New IC200ERM001
Price: $178
7 In Stock
1 Year PDF Supply Warranty

*Need a Specific Revision?

Other IC200ERM001

Available Revisions:

Confirm Your Revision Number

1C200ERM001 , GEFIC200ERM001 , CIMIC200ERM001

The IC200ERM001

The IC200ERM001

Troubleshooting IC200ERM001

Troubleshooting information is available on IC200ERM001's website page; it also includes a datasheet user-manual and a wiring diagram.

Price and Availability for IC200ERM001

Price for IC200ERM001 is available by calling 1-800-360-6802 or by filling out our "fast quote". PDF Supply has over 30 years of experience with PLCs and has experience with the GE Fanuc Versamax Series dating back to 1995. IC200ERM001 comes with a minimum 1 year PDF Supply warranty. Returns are accepted for most unopened items. It does require pre-approval and RMA.

Repair your IC200ERM001

PDF Supply can repair your IC200ERM001 in 3-5 business days. And PDF Supply stands by all of its repairs with a 2 year customer satisfaction warranty.
