Product Description

The IC200MDD845 is a mixed module made by GE Fanuc and is capable of supporting discrete inputs and outputs.
This device provides two groups of eight inputs and one group of eight outputs for a total of 24 points. The outputs for this device are relay outputs with Form A and are individually isolated. When the output logic bit is set to “1” and the central processing unit for the host is active, the output contact points are closed. Input points which receive current from devices and return it to the common line or vice versa can have two options: positive logic or negative logic. To use negative logic, updating to the IC200MDD845C is necessary.


The IC200MDD845 receives power from the backplane, but a second power supply will be needed to support additional loads. The amount of power that this device draws from the backplane power source is based on the number of active input and output points, up to a total maximum consumption of 270 milliamps. The number of input and output points that can be simultaneously active depends on different factors. Input point voltage is 24 volts of direct current, and output voltage varies from 0-125 volts of direct current and 0-265 volts of alternating current when in the 47-63 Hertz range.


The IC200MDD845 requires a carrier base from the IC200CHS series. This device does support channel-to-channel isolation for output points only, but internal fuses, snubbers, and other protection systems are not supported. Device status is indicated via multiple LED lights.

GE Intelligent Platforms / GE Fanuc GE Versamax

SKU 2176014  UPC 0159002523571

In Stock! Mixed 24VDC POS LOG input group 16 point / isolated 2 amp relay output 8 point. IC200M IC200MD IC200MDD

Troubleshooting and Product Information for IC200MDD845

Download product information, troubleshooting guides and operation manuals to get your PLC operational.

New IC200MDD845
Price: $265
5 In Stock
1 Year PDF Supply Warranty

*Need a Specific Revision?

Other IC200MDD845

Available Revisions:

Confirm Your Revision Number

1C200MDD845 , GEFIC200MDD845 , CIMIC200MDD845

The IC200MDD845

The IC200MDD845

Troubleshooting IC200MDD845

Troubleshooting information is available on IC200MDD845's website page; it also includes a datasheet user-manual and a wiring diagram.

Price and Availability for IC200MDD845

Price for IC200MDD845 is available by calling 1-800-360-6802 or by filling out our "fast quote". PDF Supply has over 30 years of experience with PLCs and has experience with the GE Fanuc Versamax Series dating back to 1995. IC200MDD845 comes with a minimum 1 year PDF Supply warranty. Returns are accepted for most unopened items. It does require pre-approval and RMA.

Repair your IC200MDD845

PDF Supply can repair your IC200MDD845 in 3-5 business days. And PDF Supply stands by all of its repairs with a 2 year customer satisfaction warranty.
