IC200MDL744

Buy NowIC200MDL744
IC200MDL744
IC200MDL744 Wiring

Rated 4.7/5 based on 11 ratings.
  • IC200MDL744
  • IC200MDL744 Wiring

Product Description


Part of the VersaMax family of components, the IC200MDL744 is an output module produced by GE Intelligent Platforms.
This output module has two groups of 16 discrete output points. Each output point can be one of two types: negative logic type or sinking type. These output points are responsible for load switching to the negative side of the power supply and receiving load current. Output modules such as the IC200MDL744 will require a carrier base from the IC200CHS series to function. Each output point corresponds to an LED status indicator, which are dependent on the backplane power supply but unaffected by the loads.



In addition to the standard backplane power source, an extra power supply will be necessary for switching loads. The IC200MDL744 has a 5-volt backplane current consumption of 140 milliamps. This module has two modes of operation: transistor-transistor logic mode (TTL) and voltage direct current mode (VDC). Nominal output voltage in both modes is 5 volts DC in TTL mode and 12/24 volts DC in VDC mode.



This device also supports “hot swapping,” which is the removal or insertion of a component without disconnecting the power source; however, if done improperly, both the IC200MDL744 and other backplane modules will be adversely affected.



While the IC200MDL744 does not have individual channel or point isolation, it does support group to group isolation—continuous isolation at 250 volts alternating current (AC) and one minute of isolation at 1500 volts AC. Internal fuses and other protection systems are not included with this module. Thermal derating is supported in specific circumstances such as voltage, environment temperature, and physical orientation of the module. These conditions dictate how many output points can be active at the same time.

GE Intelligent Platforms / GE Fanuc GE Versamax

SKU 2178144  UPC 0395571065771

Output 5/12/24VDC NEG LOGIC 0.5A per point (2 groups fo 16) 32 points IC200M IC200MD IC200MDL

Troubleshooting and Product Information for IC200MDL744

Download product information, troubleshooting guides and operation manuals to get your PLC operational.

New IC200MDL744
Price: $315
10 In Stock
1 Year PDF Supply Warranty

*Need a Specific Revision?

Reman IC200MDL744
Price: $135
10
In Stock

2 Year PDF Supply Warranty

*What is Remanufactured?

Save
 58%

Other IC200MDL744

Available Revisions:

Confirm Your Revision Number

1C200MDL744 , GEFIC200MDL744 , CIMIC200MDL744

The IC200MDL744

The IC200MDL744

Troubleshooting IC200MDL744

Troubleshooting information is available on IC200MDL744's website page; it also includes a datasheet user-manual and a wiring diagram.

Price and Availability for IC200MDL744

Price for IC200MDL744 is available by calling 1-800-360-6802 or by filling out our "fast quote". PDF Supply has over 30 years of experience with PLCs and has experience with the GE Fanuc Versamax Series dating back to 1995. IC200MDL744 comes with a minimum 1 year PDF Supply warranty. Returns are accepted for most unopened items. It does require pre-approval and RMA.

Repair your IC200MDL744

PDF Supply can repair your IC200MDL744 in 3-5 business days. And PDF Supply stands by all of its repairs with a 2 year customer satisfaction warranty.
