The IC200NDD010 is a VersaMax Nano PLC designed by GE
. The IC200NDD010 operates from +12VDC nominal input power. The IC200NDD010 has six 12VDC inputs and four DC transistor outputs.

The IC200NDD010 has six configurable DC inputs that can be constructed as a standard or HSC input with characteristics being positive or negative. If input is operating as standard, the features are compatible with an extensive range of input devices. Devices included are pushbuttons, limit switches, and electronic proximity switches. The four transistor outputs can be created as normal outputs or outputs that the High-Speed counters regulate. If regulations of outputs are controlled by the High- Speed Counters, they can then be configured as Pulse Train and/or Pulse Width Modulation (PWM) outputs. The outputs of the IC200NDD010 have one common incoming supply (VC) and one common ground (COM). The outputs’ ability to drive high inrush currents at a rate of 8 times the rated current, thus the ability to switch lamps and inductive loads.

The High-Speed Counter outputs of the IC200NDD010 have input voltages of 9V when on and 2.5V when off. The maximum frequency of the counters is 10kHZ with 20% to 80% duty cycle count-pulse width. There are a maximum of three HSC/PT and/or PWM outputs with a load voltage of 12V and a 5kHz maximum pulse frequency.

The transistor outputs of the IC200NDD010 have a voltage range of 12VDC with a maximum load of 0.7A per circuit, 4A per common. The transistor outputs of the IC200NDD010 have an output voltage drop of 0.3V maximum and off-state leakage of 0.1mA maximum.

GE Intelligent Platforms / GE Fanuc GE Versamax

SKU 2177459  UPC 0195584828864

10 point PLC, (6) 12VDC In, (4) 12VDC Out, 12VDC Power Supply IC200N IC200ND IC200NDD
